LIV ROVE 4

Tech & Features

ALUXX Aluminum Technology
This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.

D-Fuse Seatpost
The proprietary “D” shaped composite seatpost damps vibration, resulting in a smooth, compliant ride.

Specifications

Frame: ALUXX-grade aluminum, disc
Fork: SR Suntour NEX HLO 700C, 63mm, disc, lockout without rebound
Shock: N/A
Handlebar: Giant Connect XC, 31.8mm, 9-degree/6-degree rise XS: 640mm, S: 640mm, M: 680mm, L: 680mm
Grips: Liv ErgoContact
Stem: Giant Sport XS: 70mm, S: 80mm, M: 80mm, L: 90mm
Seatpost: Giant D-Fuse, alloy XS: 300mm, S: 300mm, M: 300mm, L: 350mm
Saddle: Liv Ergo Contact
Pedals: platform
Shifters: Shimano Rapidfire Plus, 2x7
Front Derailleur: Shimano Tourney
Rear Derailleur: Shimano Tourney
Brakes: Tektro TKD143, hydraulic disc [F]160mm, [R]160mm
Brake Levers: Tektro TKD149
Cassette: CS-HG200, 12x32
Chain: KMC Z7
Crankset: forged alloy, 30/46 with chainguard XS: 165mm, S: 170mm, M: 170mm, L: 170mm
Bottom Bracket: threaded
Rims: Giant SX Disc
Hubs: alloy, 28h
Spokes: stainless steel, 14g
Tires: Giant CrossCut, 700x42c, puncture protect
Extras: 55c max tire size without fender, 45c max tire size with fender, reflective stickers, kickstand, fender and rack frame mounts
Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
